承接上文在looper中会在一开始就创建一个MessageQueue，并且在loop中每次都会从其中取出一个message处理。那么我们就来看看这个MessageQueue：
MessageQueue(boolean quitAllowed) { mQuitAllowed = quitAllowed; mPtr = nativeInit(); } nativeInit，无可避免的又要进入c层进行分析。对应的文件是/frameworks/base/core/jni/android_os_MessageQueue.cpp：
static jlong android_os_MessageQueue_nativeInit(JNIEnv* env, jclass clazz) { NativeMessageQueue* nativeMessageQueue = new NativeMessageQueue(); if (!nativeMessageQueue) { jniThrowRuntimeException(env, "Unable to allocate native queue"); return 0; } nativeMessageQueue->incStrong(env); return reinterpret_cast (nativeMessageQueue);} 这里创建了一个新的NativeMessageQueue并返回他的指针。这个类的定义也在此文件中，看看他的构造做了什么：
NativeMessageQueue::NativeMessageQueue() : mPollEnv(NULL), mPollObj(NULL), mExceptionObj(NULL) { mLooper = Looper::getForThread(); if (mLooper == NULL) { mLooper = new Looper(false); Looper::setForThread(mLooper); }} 新建了一个Looper对象，这个肯定不是java层的那个了，但是前后都有getForThread和setForThread。那么他们分别在干什么呢？我的理解是在做tls线程本地变量的处理，确保本线程只有一个looper。具体的内容在这里不再论述，后续有机会可以剖析下。
我们下面来看看这个Looper是什么吧，他的构造函数如下：
Looper::Looper(bool allowNonCallbacks) : mAllowNonCallbacks(allowNonCallbacks), mSendingMessage(false), mPolling(false), mEpollFd(-1), mEpollRebuildRequired(false), mNextRequestSeq(0), mResponseIndex(0), mNextMessageUptime(LLONG_MAX) { mWakeEventFd = eventfd(0, EFD_NONBLOCK | EFD_CLOEXEC); LOG_ALWAYS_FATAL_IF(mWakeEventFd < 0, "Could not make wake event fd: %s", strerror(errno)); AutoMutex _l(mLock); rebuildEpollLocked();} 除了状态的值得设置外，就是rebuildEpollLocked：
void Looper::rebuildEpollLocked() { // Close old epoll instance if we have one. if (mEpollFd >= 0) {#if DEBUG_CALLBACKS ALOGD("%p ~ rebuildEpollLocked - rebuilding epoll set", this);#endif close(mEpollFd); } // Allocate the new epoll instance and register the wake pipe. mEpollFd = epoll_create(EPOLL_SIZE_HINT); LOG_ALWAYS_FATAL_IF(mEpollFd < 0, "Could not create epoll instance: %s", strerror(errno)); struct epoll_event eventItem; memset(& eventItem, 0, sizeof(epoll_event)); // zero out unused members of data field union eventItem.events = EPOLLIN; eventItem.data.fd = mWakeEventFd; int result = epoll_ctl(mEpollFd, EPOLL_CTL_ADD, mWakeEventFd, & eventItem); LOG_ALWAYS_FATAL_IF(result != 0, "Could not add wake event fd to epoll instance: %s", strerror(errno)); for (size_t i = 0; i < mRequests.size(); i++) { const Request& request = mRequests.valueAt(i); struct epoll_event eventItem; request.initEventItem(&eventItem); int epollResult = epoll_ctl(mEpollFd, EPOLL_CTL_ADD, request.fd, & eventItem); if (epollResult < 0) { ALOGE("Error adding epoll events for fd %d while rebuilding epoll set: %s", request.fd, strerror(errno)); } }} 我们看到了什么？epoll。这不是linux中的epoll吗？就是这个玩意，为了控制多个fd（文件描述符）的读写等事件而诞生的，一般多用于网络开发，类似win上的完成端口。然后新建了一个eventItem用于监听mWakeEventFd，就是将唤醒的eventfd放到epoll的监听队列中，用于唤醒机制。然后呢，进行了一个循环，取出所有的request，并且都放到了epoll监听，首次调用这个for循环不会被执行，因为mRequests的size是0。这些request都是什么呢？看定义：
struct Request { int fd; int ident; int events; int seq; sp callback; void* data; void initEventItem(struct epoll_event* eventItem) const; }; 那么他们对应的具体内容又是什么呢？先放一放，往下看。
回到java层的loop函数中，每次调用next方法获取message，那么看看这个MessageQueue的next方法：
Message next() { // Return here if the message loop has already quit and been disposed. // This can happen if the application tries to restart a looper after quit // which is not supported. final long ptr = mPtr; if (ptr == 0) { return null; } int pendingIdleHandlerCount = -1; // -1 only during first iteration int nextPollTimeoutMillis = 0; for (;;) { if (nextPollTimeoutMillis != 0) { Binder.flushPendingCommands(); } nativePollOnce(ptr, nextPollTimeoutMillis); synchronized (this) { // Try to retrieve the next message. Return if found. final long now = SystemClock.uptimeMillis(); Message prevMsg = null; Message msg = mMessages; if (msg != null && msg.target == null) { // Stalled by a barrier. Find the next asynchronous message in the queue. do { prevMsg = msg; msg = msg.next; } while (msg != null && !msg.isAsynchronous()); } if (msg != null) { if (now < msg.when) { // Next message is not ready. Set a timeout to wake up when it is ready. nextPollTimeoutMillis = (int) Math.min(msg.when - now, Integer.MAX_VALUE); } else { // Got a message. mBlocked = false; if (prevMsg != null) { prevMsg.next = msg.next; } else { mMessages = msg.next; } msg.next = null; if (DEBUG) Log.v(TAG, "Returning message: " + msg); msg.markInUse(); return msg; } } else { // No more messages. nextPollTimeoutMillis = -1; } // Process the quit message now that all pending messages have been handled. if (mQuitting) { dispose(); return null; } // If first time idle, then get the number of idlers to run. // Idle handles only run if the queue is empty or if the first message // in the queue (possibly a barrier) is due to be handled in the future. if (pendingIdleHandlerCount < 0 && (mMessages == null || now < mMessages.when)) { pendingIdleHandlerCount = mIdleHandlers.size(); } if (pendingIdleHandlerCount <= 0) { // No idle handlers to run. Loop and wait some more. mBlocked = true; continue; } if (mPendingIdleHandlers == null) { mPendingIdleHandlers = new IdleHandler[Math.max(pendingIdleHandlerCount, 4)]; } mPendingIdleHandlers = mIdleHandlers.toArray(mPendingIdleHandlers); } // Run the idle handlers. // We only ever reach this code block during the first iteration. for (int i = 0; i < pendingIdleHandlerCount; i++) { final IdleHandler idler = mPendingIdleHandlers[i]; mPendingIdleHandlers[i] = null; // release the reference to the handler boolean keep = false; try { keep = idler.queueIdle(); } catch (Throwable t) { Log.wtf(TAG, "IdleHandler threw exception", t); } if (!keep) { synchronized (this) { mIdleHandlers.remove(idler); } } } // Reset the idle handler count to 0 so we do not run them again. pendingIdleHandlerCount = 0; // While calling an idle handler, a new message could have been delivered // so go back and look again for a pending message without waiting. nextPollTimeoutMillis = 0; } } 首先看到获取了mPtr，这个ptr就是c层的nativeMessageQueue的地址。然后进入了一个死循环，率先走了一个nativePollOnce(ptr, nextPollTimeoutMillis);内部调用了android_os_MessageQueue_nativePollOnce：
static void android_os_MessageQueue_nativePollOnce(JNIEnv* env, jobject obj, jlong ptr, jint timeoutMillis) { NativeMessageQueue* nativeMessageQueue = reinterpret_cast (ptr); nativeMessageQueue->pollOnce(env, obj, timeoutMillis);} 这里实际上还原了地址为NativeMessageQueue对象，并调用了pollOnce方法：
void NativeMessageQueue::pollOnce(JNIEnv* env, jobject pollObj, int timeoutMillis) { mPollEnv = env; mPollObj = pollObj; mLooper->pollOnce(timeoutMillis); mPollObj = NULL; mPollEnv = NULL; if (mExceptionObj) { env->Throw(mExceptionObj); env->DeleteLocalRef(mExceptionObj); mExceptionObj = NULL; }} 保留了pollObj对象，并且调用了Looper的pollOnce。相当于c层Looper的初始化。那么来看看pollOnce：
int Looper::pollOnce(int timeoutMillis, int* outFd, int* outEvents, void** outData) { int result = 0; for (;;) { while (mResponseIndex < mResponses.size()) { const Response& response = mResponses.itemAt(mResponseIndex++); int ident = response.request.ident; if (ident >= 0) { int fd = response.request.fd; int events = response.events; void* data = response.request.data;#if DEBUG_POLL_AND_WAKE ALOGD("%p ~ pollOnce - returning signalled identifier %d: " "fd=%d, events=0x%x, data=%p", this, ident, fd, events, data);#endif if (outFd != NULL) *outFd = fd; if (outEvents != NULL) *outEvents = events; if (outData != NULL) *outData = data; return ident; } } if (result != 0) {#if DEBUG_POLL_AND_WAKE ALOGD("%p ~ pollOnce - returning result %d", this, result);#endif if (outFd != NULL) *outFd = 0; if (outEvents != NULL) *outEvents = 0; if (outData != NULL) *outData = NULL; return result; } result = pollInner(timeoutMillis); }} 一个死循环，里面先是一个while，优先处理应答response（一个request对应一个response），并返回。如果没有response需要处理的时候，走pollInner。这个pollInner是个关键，代码比较多，我们节选看：
...... struct epoll_event eventItems[EPOLL_MAX_EVENTS]; int eventCount = epoll_wait(mEpollFd, eventItems, EPOLL_MAX_EVENTS, timeoutMillis); ...... for (int i = 0; i < eventCount; i++) { int fd = eventItems[i].data.fd; uint32_t epollEvents = eventItems[i].events; if (fd == mWakeEventFd) { if (epollEvents & EPOLLIN) { awoken(); } else { ALOGW("Ignoring unexpected epoll events 0x%x on wake event fd.", epollEvents); } } else { ssize_t requestIndex = mRequests.indexOfKey(fd); if (requestIndex >= 0) { int events = 0; if (epollEvents & EPOLLIN) events |= EVENT_INPUT; if (epollEvents & EPOLLOUT) events |= EVENT_OUTPUT; if (epollEvents & EPOLLERR) events |= EVENT_ERROR; if (epollEvents & EPOLLHUP) events |= EVENT_HANGUP; pushResponse(events, mRequests.valueAt(requestIndex)); } else { ALOGW("Ignoring unexpected epoll events 0x%x on fd %d that is " "no longer registered.", epollEvents, fd); } } } ...... epoll_wait在mEpollFd上阻塞等待，直到有事件发生。如果等到了就执行下面的for循环，枚举每一个epoll_event，如果等待到的消息是唤醒消息（fd==mWakeEventFd），则执行awoken唤醒，否则判断epollEvents是否含有相关事件，如果有填写生成好的events，这个应该是转换一下事件为了上层使用。然后进行了pushResponse的动作，这里终于有个response生成的过程了，继续看下去：
void Looper::pushResponse(int events, const Request& request) { Response response; response.events = events; response.request = request; mResponses.push(response);} 看到了吧，就是个填充response的过程，并将其push到mResponses中。再回到pollInner中往下看：
......Done: ; // Invoke pending message callbacks. mNextMessageUptime = LLONG_MAX; while (mMessageEnvelopes.size() != 0) { nsecs_t now = systemTime(SYSTEM_TIME_MONOTONIC); const MessageEnvelope& messageEnvelope = mMessageEnvelopes.itemAt(0); if (messageEnvelope.uptime <= now) { // Remove the envelope from the list. // We keep a strong reference to the handler until the call to handleMessage // finishes. Then we drop it so that the handler can be deleted *before* // we reacquire our lock. { // obtain handler sp handler = messageEnvelope.handler; Message message = messageEnvelope.message; mMessageEnvelopes.removeAt(0); mSendingMessage = true; mLock.unlock();#if DEBUG_POLL_AND_WAKE || DEBUG_CALLBACKS ALOGD("%p ~ pollOnce - sending message: handler=%p, what=%d", this, handler.get(), message.what);#endif handler->handleMessage(message); } // release handler mLock.lock(); mSendingMessage = false; result = POLL_CALLBACK; } else { // The last message left at the head of the queue determines the next wakeup time. mNextMessageUptime = messageEnvelope.uptime; break; } } ...... 一上来就是一个while循环，处理一下之前堆积的事件。注意，这里是c层（native层）自己的消息，与java层的没关系。这里有个时间的对比，如果每个messageEnvelope的uptime<=now，也即是小于等于当前时间，那么这个uptime是个什么呢？我的理解是一个唤醒时间，也就是message的执行时间，因为message是允许被后置一段时间执行的。如果需要被执行的时间比当前时间晚，就调用这个message的handler的handleMessage。看起来很合理，就是为了清除一下之前堆积还未执行的事件的handle的回调。
之后又是一个for循环：...... for (size_t i = 0; i < mResponses.size(); i++) { Response& response = mResponses.editItemAt(i); if (response.request.ident == POLL_CALLBACK) { int fd = response.request.fd; int events = response.events; void* data = response.request.data;#if DEBUG_POLL_AND_WAKE || DEBUG_CALLBACKS ALOGD("%p ~ pollOnce - invoking fd event callback %p: fd=%d, events=0x%x, data=%p", this, response.request.callback.get(), fd, events, data);#endif // Invoke the callback. Note that the file descriptor may be closed by // the callback (and potentially even reused) before the function returns so // we need to be a little careful when removing the file descriptor afterwards. int callbackResult = response.request.callback->handleEvent(fd, events, data); if (callbackResult == 0) { removeFd(fd, response.request.seq); } // Clear the callback reference in the response structure promptly because we // will not clear the response vector itself until the next poll. response.request.callback.clear(); result = POLL_CALLBACK; } } ...... 这里就是处理response了，就是走一个response.request.callback->handleEvent。
我们现在继续找线索下，在Looper的构造中出现了mWakeEventFd = eventfd(0, EFD_NONBLOCK | EFD_CLOEXEC);，这个eventfd就是用来支持进程或者线程间通讯的通道，类似管道。好吧，这个过程基本上分析完毕了，其实就是通过epoll不断的处理消息，并且调用消息的回调。但是其实整个过程还有很多不是很明确的地方，例如：1.这个epoll绑定的fd到底是个什么东西？是管道吗？网上的文章基本上都是说管道，这里我没有找到线索，不好确定。2.这个c层的looper中的sendmessage已经很明确是根据传递进来的参数来设定messageEnvelope的handler。但是调用他的是哪个东西呢？怎么和java层结合起来呢？有不少问题。
